Description
Dimensions:
Travel Length: 5.8 inches
Collapsed Length: 12 inches
Extended Length: 17.89 inches
Collapsed Length: 304.8mm
Extended Length: 454.3mm
Compression: Linear
Rebound: Linear
Bilstein AS2 Series of shock absorbers feature an all new modular design that allow this shock to be utilized in many different motorsport applications.
Features:
-46mm Threaded And Hard Anodized Monotube Shock Body
-Billet Aluminum End Cap
-Your Choice Of Either Linear Or Digressive Piston Designs
-Easy Disassembly And Reassembly For Fast Repairs Or Revalving
-1/2 Inch Heim Mounts
-Parts are Economically Priced And Available For Individual Purchase
-Valve Stacks and Valve Stacking Kits Available Separately for Endless Amounts of Setup Combinations
-Non Adjustable Hard Chrome Shafts Are Standard
-Single And Double Adjustable Shaft Assemblies Are Available As An Upgrade
Collapsed Length (IN) – 12
Extended Length (IN) – 17.89
Stroke (IN) – 5.89
Lower Mount Type – 1/2in Heim
Upper Mount Type – 1/2in Heim
Boot Included – No
Finish – Clear Anodized
Internal Design – Monotube
