Description
Product information
| Weight | 47.85 lbs |
|---|---|
| Dimensions | 23.4 × 10.2 × 8.6 in |
| Material |
Aluminum |
| Color |
Natural |
| Finish |
Natural |
| Quantity |
Each |
| Product Line |
BB-2 Plus |
| Assembled/Bare |
Assembled |
| Chamber Volume |
119 cc |
| Plug Angle |
Angle |
| Intake Runner Volume |
312 cc |
| Intake Port Shape |
Rectangle |
| Intake Port Location |
Stock |
| Exhaust Port Shape |
Round |
| Exhaust Port Location |
Raised |
| Intake Valve Size |
2.250 in |
| Intake Valve Included |
Yes |
| Intake Valve Material |
Stainless |
| Intake Valve Length |
5.318 in |
| Exhaust Valve Size |
1.880 in |
| Exhaust Valve Included |
Yes |
| Exhaust Valve Material |
Stainless |
| Exhaust Valve Length |
5.494 in |
| Valve Spring Included |
Yes |
| Valve Spring Diameter |
1.550 in |
| Valve Spring Number |
Dual |
| Valve Spring Damper |
Yes |
| Valve Spring Retainers Included |
Yes |
| Valve Spring Retainer Material |
Steel |
| Valve Locks Included |
Yes |
| Valve Lock Material |
Steel |
| Valve Lock Angle |
10 Degree |
| Valve Seal Included |
Yes |
| Valve Seal Style |
Positive Stop |
| Valve Seal Material |
PTFE |
| Rocker Studs Included |
Yes |
| Rocker Stud Size |
7/16-20 in |
| Pushrod Guide Plate Included |
Yes |
| Guide Plate Pushrod Size |
3/8 in |
| Valve Guide Included |
Yes |
| Valve Guide Material |
Bronze |
| Perimeter Mount Valve Cover |
Yes |
| Valve Seat Included |
Yes |
| Intake Valve Seat Material |
Ductile Iron |
| Exhaust Valve Seat Material |
Ductile Iron |
| Valve Seat Finish |
Machined |
| Combustion Chamber Finish |
As Cast |
| Intake Runner Finish |
As Cast |
| Exhaust Runner Finish |
As Cast |
| Intake Valve Angle |
26 Degree |
| Exhaust Valve Angle |
17 Degree |
| Accessory Bolt Holes |
Drilled and Tapped |
| Exhaust Port Raised Distance |
0.600 in |
| Brand |
BRODIX |
| Type |
Cylinder Heads |
| Condition |
New |
| Manufacturer Part Number (MPN) |
2021012 |
Description Cylinder Head – BB-2 Plus – Assembled – 2.250 / 1.880 in Valves – 312 cc Intake – 119 cc Chamber – 1.550 in Springs – Angle Plug – Aluminum – Big Block Chevy – Each Features
