Description
This system features the 4-piston, S4 caliper mounted to a 11″, 2 piece slot, drill, zinc plated rotor. The S4 caliper has D.O.T compliant dust and weather seals and uses the popular DR1 or HB100 pad type. Rotors are pre-assembled with NAS high grade stainless hardware. Billet aluminum hubs come assembled with premium bearings packed with Redline synthetic grease, billet dust caps and come pre-assembled on 2″ drop spindles. All mounting brackets, stainless braided hoses and hardware are also included. The 11″ SS4+ is designed just like Baer’s larger systems, but in a smaller package for 15″ wheels.
Features:
- 2-Piece, 4-Piston, S4 Caliper Manufactured in Phoenix, AZ
- CNC Machined from US Sourced Forged or Billet Aluminum
- Powder Coated Finish
- Hard Anodized Aluminum Pistons, Stainless Steel Abutments and Noise Suppression Clips
- Dual Seals, Dust/Weather & Pressure
- 2-Piece Slot, Drilled, Zinc-Plate Rotor
Specification
- Axle: Front
- Caliper: S4
- Caliper Color: Silver
- Disc Brake Caliper (Front) Piston Quantity: 4
- Disc Brake Caliper (Front) Type: Fixed
- Disc Brake Pad FMSI Number: DR1
- Disc Brake Rotor (Front) Construction: Vented
- Disc Brake Rotor (Front) Outside Diameter(IN): 11.000
- Export Description: Brake Components
- Grade Type: Performance
- Hose Material: Stainless Steel
- Includes Spindles: Yes, 2″ Drop
- Lug Count: 5 Lug
- Min Wheel Dia (verify using template)(IN): 15
- Rotor Thickness(IN): 1.020
- Rotor Type: 2-Piece
- Surface Type: Slotted, Drilled & Zinc Plated
- Template: S125A
- Wheel Lug/Bolt Pattern: 5×4.75
- Wheel Stud Size: 1/2-20″ x 2.25″
